SALELF 3

Communication, Consumer electronics, Industrial display, IoT device

Product Brief

EF3 devices are the third generation of the “ELF” series launched by Anlogic Infotech.

EF3 devices are based on 55 nm low-power technology and feature optimized power consumption and performance, delivering high functionality at low cost. Positioned in the communications, industrial control and server markets, the product supports up to 336 I/Os to meet customer board-level IO expansion application requirements.

Contact sales

Product Table

Find 8 Results

Device	DFFs	LUTs	DistributeRAM	eRAM-9K	eRAM-Total	M18*18	PLL	USER IO	USER FLASH	Package Methods	Package Size
EF3L40CG324B	4800	4800	38K	15	135K	8	2	279	8Mb	LFBGA324	15*15
EF3L90CG400B	9280	9280	73K	30	270K	16	2	335	8Mb	LFBGA400	17*17
EF3L90CG324B	9280	9280	73K	30	270K	16	2	279	8Mb	LFBGA324	15*15
EF3L50CG256B	5304	5304	42K	31	324K	\	2	206	8Mb	LFBGA256	14*14
EF3L70CG256B	7952	7952	63K	36	324K	\	2	206	8Mb	LFBGA256	14*14
EF3L40CG332B	4800	4800	38K	15	135K	8	2	279	8Mb	LFBGA324	17*17
EF3LA0CG484B	11776	11776	92K	68	612K	\	2	383	8Mb	LFBGA484	19x19
EF3LA0CG642B	11776	11776	92K	68	612k	\	2	475	8Mb	LFBGA642	23*23

Product Features
Application Scenarios
Materials Download

Product Features

Flexible logical structure

Logic scales from 1.5K to 10K LUTs, supporting up to 475 user IOs
Built-in flash

Built-in 8Mb Flash, no external device required
Enhanced security design

Each chip has a unique 64-bit DNA

Application Scenarios

Materials Download

Technical Documentation

Title

Date

Vision

Support FPGAs

Download

Question feedback

Your name*

Your company*

Phone number*

Email required for support & contact*

Please write your feedback here*

Captcha*

You can read about how we handle your personal data, your personal data rights, and how you can contact us in our privacy policy.

Submit

Sorry, you have not logged in!

We have provided FamilyOverview documents of the serial devices such as EF2\EF3\EG4, which can be downloaded without registration.

Sorry, your permission is insufficient!

If you need to activate permissions, please log in to the member first to complete your personal information, and then send the specific requirements and registered phone number to the following email. Customer service personnel will process it as soon as possible.

Sorry, your permission is insufficient!

Please login to the member first to supplement your personal information. If you need to activate permissions, please send the specific requirements and registered phone number to the following email. Customer service personnel will process it as soon as possible.

We have provided TD4.6.4, TD4.6.5, and TD4.6.6 for the development of EF2EF3EG4 series chip solutions, which can be directly downloaded;
